The system consists of an electronic temperature control system that maintains the temperature gradient (5°C/min) according to standard. Two laser sensors automatically detect when the balls fall and determine the exact softening point without manual observation.
A magnetic stirrer with electronic speed adjustment from 0 to 160 rpm ensures uniform temperature distribution in the vessel throughout the test. Real-time visualization of temperature (°C) and time (sec) enables continuous monitoring of the test progress.
The graphical touchscreen interface enables simple setting of test parameters and immediate test start. High-resolution color screen (1/4 VGA) offers complete functionality for data handling, analysis of test results, and graphical presentation.
TECHNICAL SPECIFICATIONS
| Specification | Value |
|---|---|
| Standard | EN 1427, ASTM D36, AASHTO P53 |
| Measurement method | Two laser sensors for automatic ball detection |
| Temperature control | Electronic gradient 5°C/min ±0.5°C |
| Stirrer speed | 0–160 rpm (electronically adjustable) |
| Display | 1/4 VGA color screen, touchscreen interface |
| Real-time monitoring | Temperature (°C) and time (sec) graph |
| Data handling | PC-based analysis and graphics |
| Power supply | 230V, 50/60 Hz, 0.7 kW |
